Tempalux® Family
Tempalux® GF30
Tempalux® GF30 is a 30% glass reinforced, amorphous Polyetherimide (PEI) polymer. This product offers high dielectric strength, excellent strength at elevated temperatures, high modulus, and broad chemical resistance. With 30% glass fiber reinforcement the product offers greater levels of tensile strength, stiffness, and dimensional stability over 20% glass reinforced Tempalux®.
Attributes
Colors Available
Typical Properties
Download Data Sheet | Property | Test Standard | English Units | Metric Units |
| Mechanical | |||
| Flexural Modulus | D790 | 1,.3 kpsi | 8,960 MPa |
| Flexural Strength - Break | D790 | 32.9 kpsi | 227 MPa |
| Izod Impact Resistance - Notched | D256 | 1.59 ft-lb/in | 85 J/m |
| Tensile Elongation @ Break | D638 | 3.00 % | 3.00 % |
| Tensile Modulus | D638 | 1.3 kpsi | 9,300 MPa |
| Tensile Strength @ Break | D638 | 22.9 kpsi | 158 MPa |
| Tensile Strength @ Yield | D638 | 24 kpsi | 168 MPa |
| Thermal | |||
| HDT @ 264 psi | D648 | 410 °F | 210 °C |
| HDT @ 64 psi | D648 | 413 °F | 212 °C |
| Physical | |||
| Moisture Absorption | D570 | 0.16 % | 0.16 % |
| Specific Gravity | D792 | 1.51 | 1.51 |
| Electrical | |||
| Volume Resistivity | D257 | 30,967,680 ohm-ft | 1,016,000 ohm-cm |
| *Data above is based on testing of injection molded test specimens | |||
